| Media | Compressed air |
|---|
| Operating Temperature | -34 ... 65 °C, -29 ... 149 °F |
|---|
| Port Size | 1/4" PTF |
|---|
| Drain Type | Manual |
|---|
| Filter Element | 5 μm |
|---|
| Adjustment | Knob |
|---|
| Maximum Inlet Pressure | 10 bar, 145 psi |
|---|
| Outlet Pressure Adjustment | 0.3 ... 10 bar, 4 ... 145 psi |
|---|
| Relieving / Non Relieving | Relieving |
|---|
| Flow | 38 dm3/sec, 81 scfm |
|---|
| Materials - Adjusting Knob | Acetal |
|---|
| Materials - Body | Zinc alloy |
|---|
| Materials - Bonnet | Acetal |
|---|
| Materials - Bowl | Zinc alloy |
|---|
Product Description:
The NORGREN F18 series filters are specifically designed for
compressed air and neutral gases to effectively remove liquid water
and solid impurities. The core features and details of this filter
are as follows:
- Efficient water removal and impurity filtration: This filter can swiftly and finely filter out impurities in the
liquid and gas, ensuring medium cleanliness and quiet operation.
- Automatic drainage function: Equipped with an automatic drain, featuring connection ports of
1/8-27 and 1/8-28 male pipe threads. It's important to note that
the inner diameter of the flexible pipe connecting the drain should
be at least 3/16 inch (about 5 millimeters) to avoid affecting the
drain's normal operation.
Furthermore:
- Humanized observation design: Includes a high visibility prism liquid level indicator lens,
enabling users to easily observe the liquid level inside the filter
cup and determine drainage requirements promptly.
- Durable and sturdy construction: The main components feature an aluminum body, while the filter cup
is constructed with a transparent nylon metal bowl for both
observation convenience and structural strength. Additionally, the
filter element is crafted from sintered bronze, and the sealing
material consists of chloroprene/NET elastomer, ensuring product
stability and durability during prolonged use.
Applications:
Reliable Filtering Performance:
The NORGREN F18 series filters are highly regarded for their
dependable filtering performance, making them suitable for a wide
range of applications that necessitate clean compressed air.
Widely Applicable Fields:
NORGREN's products find utility in various sectors including
factory automation, material handling, railways, energy, process
control, and life sciences. While specific references to the F18
series may not be explicitly mentioned, these fields can offer
insights into its diverse potential applications.
Core Function Assurance System:
The primary function of the F18 series is to eliminate liquid water
and solid impurities from compressed air or gas. This function is
critical for safeguarding downstream pneumatic equipment such as
cylinders and solenoid valves, thereby enhancing equipment service
life and system reliability significantly.
Support and Services:
The Product Technical Support and Services for the Pneumatic Filter
Regulator Lubricator include:
- Troubleshooting assistance for installation and operation issues.
- Guidance on maintenance and cleaning procedures.
- Instruction on how to optimize performance and efficiency.
- Information on replacement parts and accessories.
