Shape Union
Brand SMC
Series KQG2
Fitting Body Material 316 Stainless Steel
Material Grade 316
Compatible Tube Material FEP; Nylon; PFA
Fitting Side A Tube Outer Diameter 10 mm
Fitting Side B Tube Outer Diameter (Actual) 10 mm
Color Silver
Product Description:
The joint is constructed from stainless steel 304 material, and it
is designed for compatibility with copper and zinc-free
environments, as well as corrosive settings.
There are numerous models and specifications available, making it
suitable for a wide range of pneumatic systems.
The product boasts excellent circulation performance, featuring
simple and convenient plug-and-play connections that offer safe,
reliable, and long-lasting connections with the airway.
The threaded part of the joint is coated with sealant, while the M5
metric threads come equipped with sealing rings to ensure a
leak-free connection at the threaded junction.
Applications:
Industrial dust removal and environmental protection equipment
Bag type dust removal system: connecting pulse valve and air bag,
used for high-temperature dust environment in cement plant kiln
tail and steel plant sintering machine (such as DMF-Y submerged
valve matching).
Sewage treatment aeration control: corrosion-resistant design to
resist acidic media, suitable for quick connection of pneumatic
pipelines.
Food and pharmaceutical industry
Aseptic fluid delivery: Oil free design+FKM seal, compliant with
FDA standards, used for steam cleaning pipelines in filling lines
(such as KQG2H16-04S type).
High temperature disinfection system: resistant to steam at 150 ℃,
suitable for fermentation tanks and CIP cleaning pipelines.
Chemical and energy fields
Corrosive medium transmission: SUS316 material is resistant to
acids, alkalis, and solvents and is used for chemical agent
transportation pipelines.
Steam power system: The straight through structure (such as
KQG2H23-00) optimizes the connection of steam pipelines to reduce
the risk of leakage.
Automation and Pneumatic Control
Pneumatic actuator connection: Compact design integrated into the
robotic arm fixture (such as CQ2 cylinder pipeline) to improve
response speed.
Vacuum equipment: supports -100kPa vacuum environment, used for
suction cup control system in electronic semiconductor
manufacturing.
| Brand: | SMC |
|---|
| Fitting/Connector Type: | Union |
|---|
| Length: | 35 mm |
|---|
| Manufacturer: | SMC Corporation of America |
|---|
| Material: | Stainless Steel |
|---|
| Name: | SMC KQG2H10-00 KQG2 Metric Straight Union, 10 x 10 mm Nominal,
Stainless Steel |
|---|
| Nominal Size: | 10 x 10 mm |
|---|
| Product Type: | Simple |
|---|
| Series: | KQG2 |
|---|
| Temperature Rating: | -5 to 150 deg C |
|---|
| Type: | Metric Straight |
|---|
| Unit Of Measure: | EA |
|---|
| Weight: | 1.00 |
|---|
